This HPL panel from our own house brand is 6mm thick and wine red RAL 3005 in colour, on both sides. The top layer has a light stone (rock texture) appearance and has a satin finish. In addition, the panel is UV-resistant, vandal-proof and easy to clean. On delivery, they are provided with protective film on both sides. We will saw it customised for you free of charge. For this panel, we also supply screws in an identical colour.
These HPL panels consist of compressed wood fibre, which is finished on both sides with a strong resin layer. As a result, moisture does not penetrate the panels and they are completely UV-resistant. Thanks to the dense top layers, dirt does not adhere, making the panels very easy to clean. Our HPL panels are available in the following colours: white, cream, black, grey, brown, yellow, red, blue and green.
| Property | Test method | Property or attribute | Unit | Values |
| Thickness | EN 438-2.5 | Thickness | mm | 2,0 ≤ t < 3,0 ± 0,20 |
| 3,0 ≤ t < 5,0 ± 0,30 | ||||
| 5,0 ≤ t < 8,0 ± 0,40 | ||||
| 8,0 ≤ t < 12,0 ± 0,50 | ||||
| 12,0 ≤ t < 16,0 ± 0,60 | ||||
| 16,0 ≤ t < 20,0 ± 0,70 | ||||
| 20,0 ≤ t < 25,0 ± 0,80 | ||||
| 25,0 ≤ t < nader overeen te komen | ||||
| Flatness | EN 438-2.9 | Maximum deviation | mm/m | 1 side decor: |
| 2,0 ≤ t < 5,0 ± 0,50 | ||||
| 2 side decor: | ||||
| 2,0 ≤ t < 6,0 ≤ 8,0 | ||||
| 6,0 ≤ t < 10,0 ≤ 5,0 | ||||
| 10,0 ≤ t ≤ 3,0 | ||||
| Length and width | EN 438-2.6 | Length and width | mm | + 10 / 0 |
| Straighness of edges | EN 438-2.7 | Maximum deviation | mm/m | 1,5 |
| Squareness | EN 438-2.8 | Maximum deviation | mm/m | 1,5 |
| Resistance to surface wear | EN 438-2.10 | Wear resistance | Revs | IP ≥ 150 |
| Resistance to immersion in boiling water | EN 438-2.12 | Mass increase | % | CGS: 2 ≤ t < 5 ≤ 5 CGF: ≤ 7 |
| CGS: 5 ≤ t ≤ 2 CGF: ≤ 3 | ||||
| Thickness increase | % | CGS: 2 ≤ t < 5 ≤ 6 CGF: ≤ 9 | ||
| CGS: 5 ≤ t ≤ 2 CGF: ≤ 6 | ||||
| Surface appearance gloss finish | Rating | ≥ 3 | ||
| Surface appearance other finishes | ≥ 4 | |||
| Edge | ≥ 3 | |||
| Resistance to dry heat (160 °C) | EN 438-2.16 | Surface appearance gloss finish | Rating | ≥ 3 |
| Surface appearance other finishes | Rating | ≥ 4 | ||
| Resistance to wet heat (100 °C) | EN 438-2.18 | Surface appearance gloss finish | Rating | ≥ 3 |
| Surface appearance other finishes | Rating | ≥ 4 | ||
| Stability at elevated temperatures | EN 438-2.17 | Cumulative dimensional change | % | 2 ≤ t < 5 ≤ 0,40 ≤ 0,80 |
| % | 2 ≤ t ≤ 0,30 ≤ 0,60 | |||
| Resistance to impact by large diameter fall | EN 438-2.21 | Drop height | mm | 2 ≤ t < 6 ≥ 1.400 |
| 2 ≤ t ≥ 1.800 | ||||
| Indentation diameter | mm | 10 mm | ||
| Resistance to crazing (thick laminates) | EN 438-2.24 | Appearance | Rating | ≥ 4 |
| Resistance to scratching | EN 438-2.25 | Surface appearance smooth finishes | Rating | ≥ 2 |
| Surface appearance textured finishes | Rating | ≥ 3 | ||
| Resistance to staining | EN 438-2.26 | Appearance groups 1-2 | Rating | 5 |
| Appearance group 3 | Rating | ≥ 4 | ||
| Lightfastness | EN 438-2.27 | Contrast | Grey scale rating | ≥ 4 |
| Resistance to water vapour | EN 438-2.14 | Surface appearance gloss finish | Rating | ≥ 3 |
| Surface appearance other finishes | Rating | ≥ 4 | ||
| Electrical resistance | EN 61340-4-1 | RV (23° C / 50% RH) | Ohm | 1×109 – 1×1011 |
| Thermal conductivity | EN 12664: 2001 | – | W/m . °K | 0,25 |
| Coefficient of linear thermal expansion | ASTM D 696 | – | °C -1 | L = 1,6 x 10-5 ca. |
| L = 3,5 x 10-5 ca. | ||||
| Flexural strength | EN ISO 178 | Stress | ≥ 80 | |
| Flexural modulus | EN ISO 178 | Stress | ≥ 9.000 | |
| Density | ISO 1183 | Density | ≥ 1,35 |
| Test method | Norm | Classification CGF | Classification CGS |
| Small flame and radiation px | UNI 8457, UNI 9174, UNI 9177 | Class 1 | Class 1 |
| Spread of flame | BS 476-7 | Class 1 | Class 2 |
| Fire rating | DIN 4102-1 | B1 | B2 |
| Epiradiatore | NF P 92-501 | M1 | / |
| Fire behaviour of materials and components | EN 45545-2: 2013 | 2 ≤ t < 25 mm HL1 - HL2 - HL3 | 5 ≤ t ≤ 25 mm HL1 – HL2 |
| Reaction to fire | EN 13501-1 | 2 ≤ t < 6 mm B-s2,d0 t ≥ 6 mm B-s1,d0 | t ≥ 4 mm D-s2,d0 t ≥ 6 mm C-s2,d0 t ≥ 12 mm B-s1,d0 |
HPL is also a material that is easy to work with for the do-it-yourselfer. Machining it is very much like working hardwood with hard steel tools, such as a metal saw and drill. You can paint, mill, saw and drill the material. Keep in mind that HPL expands or shrinks faster than other plastic panels. Need advice on processing HPL? Our product specialists are happy to assist you with DIY advice.
Thanks to their weather resistance and sturdiness, HPL sheets are widely used for outdoor applications such as fascias and gable tops. You also see them a lot in sanitary rooms and kitchens.
Bargeboards are designed to protect your home from weather such as wind, rain and snow so they have to be able to withstand the elements.
HPL increased in popularity in construction. It has so many advantages that it will most likely replace wooden exterior cladding.
Give your bathroom a facelift without the upheaval and stress of demolition. HPL / Trespa® wall cladding offers a very attractive solution.
Would you like to attach this material to another material? Use this glue calculator to check which glue is most suitable for this.
