Brown aluminium composite panel 3 mm RAL 8011

Brown aluminium composite panel 3 mm RAL 8011

£ 37.84 / m² Excl. VAT
£ 45.41 / m² Incl. VAT

In stock
Estimated delivery period: 2 - 9 October

Total Area (sq m)
Product Price excl. VAT
  • Cut to size for FREE
  • High quality standard
  • Professional advice
  • Large assortment

Need help?

Contact our customer service

0122-3976701
Unavailable

Description Brown aluminium composite panel 3 mm RAL 8011

This Alupunel sheet is 3mm thick and brown RAL 8011 in colour. The panel has two matte sides (a gloss layer on one side and a matte finish on the other side) and is supplied within 48 hours with a protective film on both sides. You can buy a whole panel or have it cut to size by us for free.

Specifications

This brown coloured alupanel sandwich panel consists of a polyethylene core and two top layers of 0.3 mm thick aluminium. These top layers are very durable and tolerate various chemicals such as acids, bases, oils and strong solvents. In addition, the plate is insensitive to temperature changes. You can use it in temperatures from -50 ° C to + 90 ° C. Only when you have passed the 100-degree limit, will the panel will expand 2.4 millimetres per linear metre.

Material Properties

Panel size
Panel thickness (mm) 3
Aluminium thickness (mm) 0.3 (/EuroACP 0.26 mm)
Standard size 1500 x 3050
Admissible dimensional deviations
Thickness (mm) – 0 + 0.2
Width (mm) ± 2
Length (mm) ± 3
Diagonal (mm) ± 5
Thermal expansion 2.4mm/m @100°C temperature difference
Aluminium thickness (mm) ± 0.02
Surface characteristics
Paint thickness (micron) 20
Pencil hardness >HB
Strength coating 3T
Temperature tolerance -50°C to +90°C
Impact resistance (Kg Cm2) 50
Boiling water tolerance No change after 2 hours in boiling water
Acid tolerance No change in surface after 24 hours immersed in 2% HC1
Alkali tolerance No change in surface after 24 hours immersed in 2% NaOH
Oil tolerance No change in surface after 24 hours immersed in 20% motor oil
Solvent tolerance No change after 100 cleanings with Dimethylbenzene
Cleaning tolerance >1000 times without change
Flaking resistance 180. >5 Newton/mm
Product specifications
Weight (Kg m2) 3.8
Sound absorption NRC 0.05
Sound absorption Rw db 24
Water absorption in % per volume 0.01
Thermal efficiency R-values 0.0057
Composition core LDPE Polythene
Fire rating Class 1 BS476 PT7 / Class 0 BS476 P16

Indoor / outdoor use

  • Inside
  • Outside

Indoor / outdoor space

  • Chemically resistant
  • Heat resistant
  • Light sheet material
  • Moisture-proof
  • UV resistant

Processing options

Coloured Alupanel sheets are easy to process, from the aluminium top layers to the polyethylene core. Painting, drilling, sawing, milling and glueing present no problem if you use the right tools. We recommend the products of the quality brand Bostik for glueing Alupanel sheets. Do you want to clean the panels? That’s easy with a mild detergent and a soft cloth.

Applications

This brown coloured Alupanel plate is UV-resistant, lightweight and easy to work with. That is why you often find these plates in the advertising and interior design industry, for example, as façade cladding, displays and billboards.

Frequently Asked Questions

  • To calculate easily which Alupanel panel is most suitable for your application, we have developed the thickness calculator aid. Choose a vertical or horizontal installation and look up the length and width that you have in mind in the table. This gives you the thickness that you need. No rights can be derived from the thickness calculator. If you want to be sure that you have selected the correct thickness then please contact us for more advice.

Are you wondering whether the Brown aluminium composite panel 3 mm RAL 8011 is suitable for your project? Then order a sample. Then you can take your time to consider it, without having to order a whole sheet.

Shipping

  • Shipping

    We ensure that your order is ready for dispatch within 24 hours. You can track your order from door to door via the Track & Trace code.

  • Packaging Costs

    To prevent damage to larger sheets, we use special, custom-made frames to transport them. The shipping costs depend on the size and weight of the package. View the shipping cost table.
