Clear cast (GS) acrylic sheet 3 mm

Clear cast (GS) acrylic sheet 3 mm

£ 24.99 / m² Excl. VAT
£ 29.99 / m² Incl. VAT
Total Area (sq m)
Product Price excl. VAT
In stock
Delivery period: 24 - 30 September
  • Cut to size for FREE
  • Dispatch ready within 48h
  • High quality standard
  • Professional advice
Need help?

Contact our customer service

0122-3976701
Unavailable

Description Clear cast (GS) acrylic sheet 3 mm

Acrylic sheet is widely used as a replacement for glass. These transparent coloured sheets are not only thirty times stronger than glass, but also half the weight.
This type of acrylic is called “cast acrylic”. This material was cast into large sheets during production, making the sheet stress-free. This makes this clear acrylic suitable for extensive processing such as sawing, drilling, milling and (hot) bending.

Specifications

The acrylic sheets are UV-resistant, making them highly suitable for indoor and outdoor applications. The sheet has a thickness tolerance of 10 percent; this means that the thickness of the plate can actually differ from the thickness stated on this page. The sheets are supplied with a protective film on both sides and are sawn to the required size for free.

Properties

Specific mass gr/cm3 1,18
Mechanical properties (at 20°C)
Flexural strength N/mm 117,72
Stretch to breakage % 3,5
High pressure strength N/mm2 117,7
E. Modules N/mm2 3188
Indentation strength J/m2 39,24
Impact resistance KJ/m2 24,53
Tensile strength N/mm2 73,7
Friction coefficient 0,54
Water absorption at 20°C RV 65% % 0,25
Water absorption at 20°C RV 100% % 0,36
Thermal properties
processing temperature (Vivat) °C 105
Melting temperature °C 180
Linear expansion coefficient °C 70.10-6
Thermal conduction W/(k.m) 0,186
Specific heat KJ/(kg.K) 1,47
Maximum permissible temperature, without load °C 70
Minimum permissible temperature, without load °C -20
Electrical properties
Dielectric contstant 2,9
Dielectric loss factor tg 0,017
Breakdown voltage kV/mm 17
Surface resistance Ω 10 14
Specific resistance Ω.cm >10 13

Product uses

  • Chemically resistant
  • Light sheet material
  • Moisture-proof
  • UV resistant

Processing options

This clear acrylic sheet 3mm is made of cast acrylic (GS). This acrylic is very suitable for operations such as sawing, drilling, milling and (hot) bending.

Applications

Thanks to the good UV-resistant qualities of this clear acrylic sheet, it can be used for both indoor and outdoor applications. Think for example of display cases, secondary glazing and nameplates.

Frequently Asked Questions

  • Absolutely, this clear acrylic sheet is UV resistant. This makes it suitable for both indoor and outdoor use.
  • The GS sheets are moulded acrylic sheets. These sheets are stress-free, making them suitable for processes such as sawing, drilling, milling and (hot) bending.

Are you wondering whether the Clear cast (GS) acrylic sheet 3 mm is suitable for your project? Then order a sample. Then you can take your time to consider it, without having to order a whole sheet.
