Acrylic sheet is widely used as a replacement for glass. These transparent coloured sheets are not only thirty times stronger than glass, but also half the weight.
This type of acrylic is called “cast acrylic”. This material was cast into large sheets during production, making the sheet stress-free. This makes this clear acrylic suitable for extensive processing such as sawing, drilling, milling and (hot) bending.
The acrylic sheets are UV-resistant, making them highly suitable for indoor and outdoor applications. The sheet has a thickness tolerance of 10 percent; this means that the thickness of the plate can actually differ from the thickness stated on this page. The sheets are supplied with a protective film on both sides and are sawn to the required size for free.
|Mechanical properties (at 20°C)|
|Stretch to breakage||%||3,5|
|High pressure strength||N/mm2||117,7|
|Water absorption at 20°C RV 65%||%||0,25|
|Water absorption at 20°C RV 100%||%||0,36|
|processing temperature (Vivat)||°C||105|
|Linear expansion coefficient||°C||70.10-6|
|Maximum permissible temperature, without load||°C||70|
|Minimum permissible temperature, without load||°C||-20|
|Dielectric loss factor||tg||0,017|
|Surface resistance||Ω||10 14|
|Specific resistance||Ω.cm||>10 13|
This clear acrylic sheet 20mm is made of cast acrylic (GS). This acrylic is very suitable for operations such as sawing, drilling, milling and (hot) bending.
Thanks to the good UV-resistant qualities of this clear acrylic sheet, it can be used for both indoor and outdoor applications. Think for example of display cases, secondary glazing and nameplates.
