Description Clear cast (GS) acrylic sheet 15 mm

Acrylic sheet is widely used as a replacement for glass. These transparent coloured sheets are not only thirty times stronger than glass, but also half the weight.
This type of acrylic is called “cast acrylic”. This material was cast into large sheets during production, making the sheet stress-free. This makes this clear acrylic suitable for extensive processing such as sawing, drilling, milling and (hot) bending.

Specifications

The acrylic sheets are UV-resistant, making them highly suitable for indoor and outdoor applications. The sheet has a thickness tolerance of 10 percent; this means that the thickness of the plate can actually differ from the thickness stated on this page. The sheets are supplied with a protective film on both sides and are sawn to the required size for free.

Material properties

Specific mass gr/cm3 1,18
Mechanical properties (at 20°C)
Flexural strength N/mm 117,72
Stretch to breakage % 3,5
High pressure strength N/mm2 117,7
E. Modules N/mm2 3188
Indentation strength J/m2 39,24
Impact resistance KJ/m2 24,53
Tensile strength N/mm2 73,7
Friction coefficient 0,54
Water absorption at 20°C RV 65% % 0,25
Water absorption at 20°C RV 100% % 0,36
Thermal properties
processing temperature (Vivat) °C 105
Melting temperature °C 180
Linear expansion coefficient °C 70.10-6
Thermal conduction W/(k.m) 0,186
Specific heat KJ/(kg.K) 1,47
Maximum permissible temperature, without load °C 70
Minimum permissible temperature, without load °C -20
Electrical properties
Dielectric contstant 2,9
Dielectric loss factor tg 0,017
Breakdown voltage kV/mm 17
Surface resistance Ω 10 14
Specific resistance Ω.cm >10 13

Indoor / outdoor use

  • Inside
  • Outside

Indoor / outdoor space

  • Chemically resistant
  • Light sheet material
  • Moisture-proof
  • UV resistant

Processing options

This clear acrylic sheet 15mm is made of cast acrylic (GS). This acrylic is very suitable for operations such as sawing, drilling, milling and (hot) bending.

  • Bending (warm)
  • Lasering
  • Turning
  • Cutting
  • Sawing (jigsaw)
  • Sawing (circular saw)
  • Drilling
  • Polishing
  • Milling
  • Engraving
  • Glueing
  • Lettering
  • Coating
  • Bending (cold)
  • Matting
  • Painting
  • Printing
  • Shelf
  • Water cutting
  • Welding

Applications

Thanks to the good UV-resistant qualities of this clear acrylic sheet, it can be used for both indoor and outdoor applications. Think for example of display cases, secondary glazing and nameplates.
