Tinted acrylic sheet orange 3 mm

Tinted acrylic sheet orange 3 mm

£ 46.68 / m² Excl. VAT
£ 56.02 / m² Incl. VAT

In stock
Estimated delivery period: 4 - 11 November

  • Cut to size for FREE
  • High quality standard
  • Professional advice
  • Large assortment

Need help?

Contact our customer service

0122-3976701
Unavailable

Description Tinted acrylic sheet orange 3 mm

This acrylic sheet is tinted and has a thickness of 3 mm.
Thanks to its good UV-resistant qualities, this sheet can be used both indoors and outdoors. The coloured acrylic sheet can be used as display cases, kitchen splashbacks or nameplates.

Specifications

These orange coloured acrylic sheets are not only thirty times stronger than glass, but also half as light. The sheets are supplied with a protective film on both sides and are sawn to the required size for free. When ordering the acrylic sheets, bear in mind a thickness tolerance of 10%. This means that the thickness of the sheet can deviate by 10%.

Material Properties

Specific mass gr/cm3 1,18
Mechanical properties (at 20°C)
Flexural strength N/mm 117,72
Stretch to breakage % 3,5
High pressure strength N/mm2 117,7
E. Modules N/mm2 3188
Indentation strength J/m2 39,24
Impact resistance KJ/m2 24,53
Tensile strength N/mm2 73,7
Friction coefficient 0,54
Water absorption at 20°C RV 65% % 0,25
Water absorption at 20°C RV 100% % 0,36
Thermal properties
processing temperature (Vivat) °C 105
Melting temperature °C 180
Linear expansion coefficient °C 70.10-6
Thermal conduction W/(k.m) 0,186
Specific heat KJ/(kg.K) 1,47
Maximum permissible temperature, without load °C 70
Minimum permissible temperature, without load °C -20
Electrical properties
Dielectric contstant 2,9
Dielectric loss factor tg 0,017
Breakdown voltage kV/mm 17
Surface resistance Ω 10 14
Specific resistance Ω.cm >10 13

Indoor / outdoor use

Indoor / outdoor space

  • Chemically resistant
  • Light sheet material
  • Moisture-proof
  • UV resistant

Processing options

You can easily process the orange tinted acrylic sheet by drilling, bending (hot), milling, engraving, glueing, polishing or sawing.

  • Bending (warm)
  • Drilling
  • Engraving
  • Glueing
  • Lasering
  • Lettering
  • Milling
  • Polishing
  • Sawing (circular saw)
  • Sawing (jigsaw)
  • Turning
  • Bending (cold)
  • Cutting
  • Painting
  • Water cutting
  • Welding

Applications

The Tinted acrylic sheet orange 3 mm  is very suitable for secondary glazing. Tinted acrylic sheet is also widely used in windbreaks.
