This hard PVC sheet is 3mm and dark grey in colour RAL 7011. The sheet has a smooth top layer with a satin finish. The uniform colour extends to the core. In comparison with our foamed variant, this hard PVC sheet is a lot heavier and more massive. Its good chemical resistance, electrical insulating capacity and self-extinction makes this material very suitable for industrial applications.
Hard PVC is a material widely used in the chemical industry, mechanical engineering and electrical engineering. The sheets are chemical and heat resistant (up to max. 70 ° C), electrically insulating, self-extinguishing, pressure-resistant and easy to process. Our dark grey PVC sheets are available up to a maximum surface area of 200 x 100 cm. We will saw them for you in the right format for free. The sheets are supplied without protective film, which means they may be slightly scratched.
| Specific mass | gr/cm3 | 1,39 |
| Mechanical properties (at 20°C) | ||
| Flexural strength | N/mm | 78,5-107,8 |
| Stretch to breakage | % | 20-50 |
| High pressure strength | N/mm2 | 78,5 |
| E. Modules | N/mm2 | 2943 |
| Indentation strength | J/m2 | 19,62-39,24 |
| Impact resistance | KJ/m2 | No breakage |
| Tensile strength | N/mm2 | 49,1-58,9 |
| Friction coefficient | 0,55 | |
| Water absorption at 20°C RV 65% | % | 0,2 |
| Water absorption at 20°C RV 100% | % | 3,5 |
| Thermal properties | ||
| processing temperature (Vivat) | °C | 80 |
| Melting temperature | °C | 120-130 |
| Linear expansion coefficient | °C | 80.10-6 |
| Thermal conduction | W/(k.m) | 0,16 |
| Specific heat | KJ/(kg.K) | 1,00 |
| Maximum permissible temperature, without load | °C | 70 |
| Minimum permissible temperature, without load | °C | -10 |
| Electrical properties | ||
| Dielectric contstant | 3,3 | |
| Dielectric loss factor | tg | 0,02-0,04 |
| Breakdown voltage | kV/mm | 40 |
| Surface resistance | Ω | 10 13 |
| Specific resistance | Ω.cm | 5.10 13 |
Hard PVC is easy to machine. With the right tools, you can saw, cut and drill. Painting, welding, milling and glueing are also not a problem. Use the correct PVC glue for the latter.
Foamed PVC sheet is an ideal material for both indoor and outdoor use. You find it a lot in the advertising industry, where the sheets are used as displays, billboards and stand material. It is also popular in construction, thanks to its good fire resistance, and the sound and heat insulating properties of the panels.
Are you wondering whether the dark grey PVC foam sheet 3 mm RAL 7011 is suitable for your project? Then order a sample. Then you can take your time to consider it, without having to order a whole sheet.
