Opal green acrylic sheet 3 mm

Description Opal green acrylic sheet 3 mm

This acrylic sheet is green and has a thickness of 3mm. Because it is a moulded acrylic sheet, it is easy to process by drilling, sawing and milling. This is why coloured acrylic is often used for decorative and finishing applications.

Specifications

This coloured acrylic sheet is 30 times stronger than glass and twice as light.
Thanks to its good UV-resistant qualities, this material is very suitable for indoor and outdoor use. The sheets are cut to size for you free of charge. Bear in mind that the thickness can deviate by approximately 10%.

Basic information
Technical specifications

Appearance Colour, Opal, Shine, Smooth
Environment Inside, Outside

Specific mass	gr/cm³	1,18

Mechanical properties (at 20°C)
Flexural strength	N/mm	117,72
Stretch to breakage	%	3,5
High pressure strength	N/mm²	117,7
E. Modules	N/mm²	3188
Indentation strength	J/m²	39,24
Impact resistance	KJ/m²	24,53
Tensile strength	N/mm²	73,7
Friction coefficient		0,54
Water absorption at 20°C RV 65%	%	0,25
Water absorption at 20°C RV 100%	%	0,36

Thermal properties
processing temperature (Vivat)	°C	105
Melting temperature	°C	180
Linear expansion coefficient	°C	70.10-⁶
Thermal conduction	W/(k.m)	0,186
Specific heat	KJ/(kg.K)	1,47
Maximum permissible temperature, without load	°C	70
Minimum permissible temperature, without load	°C	-20

Electrical properties
Dielectric contstant		2,9
Dielectric loss factor	tg	0,017
Breakdown voltage	kV/mm	17
Surface resistance	Ω	10 ¹⁴
Specific resistance	Ω.cm	>10 ¹³

Technical specifications

Specific mass	gr/cm³	1,18

Mechanical properties (at 20°C)
Flexural strength	N/mm	117,72
Stretch to breakage	%	3,5
High pressure strength	N/mm²	117,7
E. Modules	N/mm²	3188
Indentation strength	J/m²	39,24
Impact resistance	KJ/m²	24,53
Tensile strength	N/mm²	73,7
Friction coefficient		0,54
Water absorption at 20°C RV 65%	%	0,25
Water absorption at 20°C RV 100%	%	0,36

Thermal properties
processing temperature (Vivat)	°C	105
Melting temperature	°C	180
Linear expansion coefficient	°C	70.10-⁶
Thermal conduction	W/(k.m)	0,186
Specific heat	KJ/(kg.K)	1,47
Maximum permissible temperature, without load	°C	70
Minimum permissible temperature, without load	°C	-20

Electrical properties
Dielectric contstant		2,9
Dielectric loss factor	tg	0,017
Breakdown voltage	kV/mm	17
Surface resistance	Ω	10 ¹⁴
Specific resistance	Ω.cm	>10 ¹³

Processing options

Coloured acrylic sheet can be processed just as well as all other types of moulded acrylic. You can easily process these coloured sheets by means of drilling, sawing and milling.

Applications

The coloured acrylic sheets are UV resistant. This means you can use them for both indoor and outdoor applications. Think for example of display cases, windbreaks and nameplates.
