White HPL sheet 8 mm RAL 9016

White HPL sheet 8 mm RAL 9016

£ 56.05 / m² Excl. VAT
£ 67.26 / m² Incl. VAT
Total Area (sq m)
Product Price excl. VAT
In stock
Delivery period: 22 - 28 August
  • Cut to size for FREE
  • Dispatch ready within 48h
  • High quality standard
  • Professional advice
Need help?

Contact our customer service

0122-3976701
Unavailable

Description

This HPL sheet is 8 mm thick and is white with RAL 9016. The surface of the sheet is smooth with a silky glow. Both sides of the sheet are coloured. HPL sheets are a dense, hard material with a fixed form. They are well suited for both indoor and outdoor applications. This private label HPL sheet will be cut to size for you, free of charge.

Sustainable
HPL material is produced by soaking several layers of wood fibre and paper in phenolic resin and then compressing them under high temperature. This results in a rock-hard sheet with a UV resistant top layer. The HPL sheet won’t decay because moisture, sunlight, mould and wood rot cannot penetrate the dense surface of the material.

Low-maintenance
The life span of HPL sheets is 30 years and they are extremely low-maintenance. Cleaning an HPL sheet is simple because the material is impenetrable for dirt. Cleaning the sheets regularly with warm water and a mild cleaning product is all that is required. We recommend using a soft cloth or brush instead of an abrasive sponge, since this can leave the surface scratched and with a matt appearance.

Easy to process
With the right DIY tools HPL sheets are easy to work with. In our blog sections you can find several tips and tricks to get the job done. Here you will find articles on sawing, gluing, drilling and painting HPL sheets.

Characteristics
HPL sheets have a few important characteristics. The following aspects are good to know about our private label HPL sheets:

  • Colour: white RAL 9016 (this is a colour indication; our sheets are not bound to RAL colours)
  • Maximum sheet size: 305 x 130 cm
  • Thickness top layer: 0.8 mm
  • Double sided: both sides can be used as visible side
  • UV and heat resistance: High
  • Life span: 30 years
  • When sawing HPL sheets to size, the edges can get slightly damaged. Unfortunately, this cannot be prevented. The possible damaged area will never be wider than 0.5 mm.
  • Thickness tolerance of 10%

Workability
HPL is an extremely tough plastic and can only be altered by using the right equipment. We recommend using tools that are suitable for working on hard wood. With the right tools, the following alterations can be accomplished:

  • Sawing
  • Milling
  • Drilling
  • Painting

Applications
HPL is a versatile plastic that can be used for many different purposes. Indoors, HPL is regularly used in areas where hygiene plays an important role. Outdoors, HPL is used for many applications, including billboards and fascia boards.

  • Fascia boards
  • Exterior cladding
  • Billboards
  • Hygienic areas (laboratory/operating rooms)
  • Desks

Specifications

Property Test method Property or attribute Unit Values
Thickness EN 438-2.5 Thickness mm 2,0 ≤ t <   3,0   ± 0,20
3,0 ≤ t <   5,0   ± 0,30
5,0 ≤ t <   8,0   ± 0,40
8,0 ≤ t < 12,0   ± 0,50
12,0 ≤ t < 16,0   ± 0,60
16,0 ≤ t < 20,0   ± 0,70
20,0 ≤ t < 25,0   ± 0,80
25,0 ≤ t < nader overeen te komen
Flatness EN 438-2.9 Maximum deviation mm/m 1 side decor:
2,0 ≤ t < 5,0   ± 0,50
2 side decor:
2,0 ≤ t <   6,0   ≤ 8,0
6,0 ≤ t < 10,0   ≤ 5,0
10,0 ≤ t              ≤ 3,0
Length and width EN 438-2.6 Length and width mm + 10 / 0
Straighness of edges EN 438-2.7 Maximum deviation mm/m 1,5
Squareness EN 438-2.8 Maximum deviation mm/m 1,5
Resistance to surface wear EN 438-2.10 Wear resistance Revs IP ≥ 150
Resistance to immersion in boiling water EN 438-2.12 Mass increase % CGS: 2 ≤ t < 5 ≤ 5        CGF: ≤ 7
CGS: 5 ≤ t       ≤ 2        CGF: ≤ 3
Thickness increase % CGS: 2 ≤ t < 5 ≤ 6        CGF: ≤ 9
CGS: 5 ≤ t       ≤ 2        CGF: ≤ 6
Surface appearance gloss finish Rating ≥ 3
Surface appearance other finishes ≥ 4
Edge ≥ 3
Resistance to dry heat (160 °C) EN 438-2.16 Surface appearance gloss finish Rating ≥ 3
Surface appearance other finishes Rating ≥ 4
Resistance to wet heat (100 °C) EN 438-2.18 Surface appearance gloss finish Rating ≥ 3
Surface appearance other finishes Rating ≥ 4
Stability at elevated temperatures EN 438-2.17 Cumulative dimensional change % 2 ≤ t < 5   ≤ 0,40   ≤ 0,80
% 2 ≤ t   ≤ 0,30   ≤ 0,60
Resistance to impact by large diameter fall EN 438-2.21 Drop height mm 2 ≤ t  < 6   ≥ 1.400
2 ≤ t          ≥ 1.800
Indentation diameter mm 10 mm
Resistance to crazing (thick laminates) EN 438-2.24 Appearance Rating ≥ 4
Resistance to scratching EN 438-2.25 Surface appearance smooth finishes Rating ≥ 2
Surface appearance textured finishes Rating ≥ 3
Resistance to staining EN 438-2.26 Appearance groups 1-2 Rating 5
Appearance group 3 Rating ≥ 4
Lightfastness EN 438-2.27 Contrast Grey scale rating ≥ 4
Resistance to water vapour EN 438-2.14 Surface appearance gloss finish Rating ≥ 3
Surface appearance other finishes Rating ≥ 4
Electrical resistance EN 61340-4-1 RV (23° C / 50% RH) Ohm 1×109 – 1×1011
Thermal conductivity EN 12664: 2001 W/m . °K 0,25
Coefficient of linear thermal expansion ASTM D 696 °C -1 L = 1,6 x 10-5 ca.
L = 3,5 x 10-5 ca.
Flexural strength EN ISO 178 Stress ≥ 80
Flexural modulus EN ISO 178 Stress ≥ 9.000
Density ISO 1183 Density ≥ 1,35



Test method Norm Classification CGF Classification CGS
Small flame and radiation px UNI 8457, UNI 9174, UNI 9177 Class 1 Class 1
Spread of flame BS 476-7 Class 1 Class 2
Fire rating DIN 4102-1 B1 B2
Epiradiatore NF P 92-501 M1 /
Fire behaviour of materials and components EN 45545-2: 2013 2 ≤ t < 25 mm    HL1 – HL2 – HL3 5 ≤ t ≤ 25 mm    HL1 – HL2
Reaction to fire EN 13501-1 2 ≤ t < 6 mm    B-s2,d0    t ≥ 6 mm B-s1,d0 t ≥ 4 mm D-s2,d0    t ≥ 6 mm C-s2,d0    t ≥ 12 mm B-s1,d0
White HPL sheet RAL 9016

Order a sample of this product and get the costs returned when you place an order
