Green PVC foam sheet 3 mm RAL 6024

Green PVC foam sheet 3 mm RAL 6024

£ 19.95 / m² Excl. VAT
£ 23.94 / m² Incl. VAT

In stock
Estimated delivery period: 2 - 9 October

Total Area (sq m)
Product Price excl. VAT
  • Cut to size for FREE
  • High quality standard
  • Professional advice
  • Large assortment

Need help?

Contact our customer service


Description Green PVC foam sheet 3 mm RAL 6024

Are you looking for a coloured PVC foam board? Then you’ve come to the right place. We have a wide range of PVC foam sheets in various colours, from white, yellow, red and blue to grey, green, black, ivory and orange. Our foamed PVC sheets are particularly light in weight (half as light as hard PVC) and consist of a hard foam core. This core is laminated with paper on both sides. The top layer is lightly textured, giving the coloured PVC sheets an attractive matte appearance.


This foamed PVC sheet is 3mm and green in colour RAL 6024. This colour code is an indication. Our plates are not bound to a RAL colour. Do you want to know for sure if the colour of this PVC foamed sheet suits your project? Request a sample. This sheet is available up to a maximum surface area of 305 x 156 cm. We will cut the sheet for you in the right format for free.

Material properties

Specific mass gr/cm3 1,25
Mechanical properties (at 20°C)
Flexural strength N/mm
Stretch to breakage % 370-400
High pressure strength N/mm2
E. Modules N/mm2 49,0
Indentation strength J/m2 No breakage
Impact resistance KJ/m2 No breakage
Tensile strength N/mm2 15,7-17,6
Friction coefficient
Water absorption at 20°C RV 65% % 0,2
Water absorption at 20°C RV 100% %
Thermal properties
processing temperature (Vivat) °C 50-60
Melting temperature °C 165
Linear expansion coefficient °C 70.100.10-6
Thermal conduction W/(k.m)
Specific heat KJ/(kg.K) 1,26-1,47
Maximum permissible temperature, without load °C 50
Minimum permissible temperature, without load °C 0
Electrical properties
Dielectric contstant 7,5-8
Dielectric loss factor tg 0,08
Breakdown voltage kV/mm 24-26
Surface resistance Ω 10 11
Specific resistance Ω.cm 5.10 11

Indoor / outdoor use

  • Inside

Indoor / outdoor space

  • Light sheet material

Editing options

Foamed PVC is easily workable. Painting, glueing, sawing, drilling and milling is no problem. Another advantage of PVC is that it requires little maintenance and is easy to clean. You will find the required products for cleaning in our webshop. All our sheets are supplied with a special foil to offer protection when processing the material.


Foamed PVC sheet is an ideal material for both indoor and outdoor use. You find it a lot in the advertising industry, where the sheets are used as displays, billboards and stand material. It is also popular in construction, thanks to its good fire resistance, and the sound and heat insulating properties of the panels.

Frequently Asked Questions

  • PVC stands for polyvinyl chloride. This is a high-quality plastic with high chemical resistance. PVC is electrically insulating and very form-retaining. PVC sheets are available in two types: solid (hard) and foamed sheets.
  • PVC foam sheet is a particularly light material. It is approximately 50% lighter than the hard PVC sheets. The hard version is stiffer and retains its shape. The particular application and desired processability will determine which type of PVC fits your project. White foamed PVC is very suitable for advertising purposes. We recommend hard PVC for applications in mechanical engineering or electrical engineering. Do you want to be sure that you are making the right choice? Then please contact our customer service via 085-7325800.
  • Our PVC foamed sheets are protected on the decor side by a protective film. The back may have some light scratches due to sawing. By sawing, a small corner of a maximum of 1x1 mm can break off, unfortunately, this cannot be prevented. If your order is damaged in a different way to that mentioned above, please contact our customer service via 085-7325800
  • Our items come with a six-month warranty as standard. For more information, please refer to the General Terms and Conditions.
  • This plate is resistant to temperatures up to 70 degrees Celsius and has fire class B1.
  • We calculate shipping costs based on the weight and size of the package. You will find all the information about rates and their calculation on the shipping costs page.
  • Did you have the sheet cut to size? Then, unfortunately, it is not possible to return this product. Whole sheets may, if they are undamaged and provided with protective film, be returned at your own expense. Before you send the product back, please contact us by telephone. Then we will go through the returns procedure with you and arrange for the product to be collected.

Are you wondering whether the green PVC foam sheet 3 mm RAL 6024 is suitable for your project? Then order a sample. Then you can take your time to consider it, without having to order a whole sheet.
